Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker

Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker supplier Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker supplier

Large Image :  Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker

Product Details:

Place of Origin: Guangzhou China
Brand Name: CVR
Certification: CE,RoHS
Model Number: CV-3

Payment & Shipping Terms:

Minimum Order Quantity: 2 Pieces
Price: Negotiation
Packaging Details: Carton Box & Flight Case
Delivery Time: 5--8 Work Days
Payment Terms: D/A, D/P, L/C, Western Union
Supply Ability: 1000 Pieces Per Month
Detailed Product Description
Model Number:: CV-3 Type: Three Way Full Range System
Brand Name: CVR Power:: 2000W(RMS)4000W(PEAK)
Input Connectors:: 2-Neutrik NL4 Size: 2X15" Woofers
Finish: Black Paint

Outdoor Passive Pa System Stage Audio Speaker Box Concert Equipment , Dj Sound Speaker


Our Unique Advantage:

           Small order accept

  •
  •  Green Paint, low pollution
  •
  •  Flat aluminum wire for the woofer
  •
  •  All are textured, durable birch plywood
  •
  •  Plug is Neutrik, endure repeatedly plug
  •
  •  Import loudspeaker cone, good elasticity for woofer


Package and Delivery:

  1. --Carton or flycase
  2. --At buyers' option



DESCRIPTION and APPLICATION:


The ultra-compact CV-3 is a unique, innovative three-way, full range system. CV-3 is equipped with two 15" wave horn loading woofers,one 8"wave horn loading neodymium driver and one 3"titanium compression driver optimally splayed for smooth, powerful, mid-long throw wide coverage. Extremely versatile CV-3 blends pleasing aesthetics, uncompromising technical excellence with ease of installation to provide a high quality loudspeaker system to suit installed sound requirements of varied sizes venues such as bars, night clubs, conference centers, stadiums, arenas, etc.



ModelCV-3
TypeTree-way full range system
Frequency Response45Hz-18kHz±3dB
Power handling1600W(RMS)3200W(PEAK)
Sensitivity105dB(1W@1M)
Max@S.P.L135dB(PEAK/1M)
LF section15"(380mm) woofer 100mm
(4in)coil
MF section8"(200mm) neodymium MF
65mm(2.75in)coil
HF section3"compression driver with
75mm titanium diaphragm
Nominal impedance4 ohm
Output section3-channel
Dispersion pattern60°H×40°V
Surface finishBlack paint
Speaker cables1(+)1(-)
Input connectors2×NL4MP speakon
Dimensions490×1210×540mm(W×H×D)
Package dimensions560×1280×610mm/0.43cbm
EnclosurePlywood
Net weight71kg
Gross weight76kg



CVR PRO AUDIO Exclusive area:
Japan, Korea, Peru, USA,Ghana,Uganda,Nigeria,Combodia
 USA Address:2012 TRANQUILITY LANE,LEAGUE CITY, TX 77573,USA
 Japan Address: 329 AOKI YUASA-TOWN ARIDA-GUN, WAKAYAMA-prefecture
 Korea Address:408,Onnuriplaza,128-2,Goean-dong,Sosa-gu,Bucheon-si,Kyungki
Ghana Address:No.9,5th Circular road,Labone Accra
Peru Address:Jr.paruro 1359 tda.159 Lima

 Uganda Address: Plot 1175A Mukalazi Road, Bukoto Kampala Uganda. P.O BOX 23217Kampala
 Nigeria Address: T. I. REWARD BLOCK, ELECTRONICS MARKET ONITSHA, ANAMBRA STATE.
 Combodia Address: #288D Mao Tse Tong Blvd., Sangkat Tumnup Teok, Khan Chamkarmon, Phnom Penh.

CVR Audio is looking for more distributors,please email us for more details information.
